2003-2009 Dodge Ram Install Guide

2003-2009 INSTALLATION GUIDE 9 GlowShift.com © GlowShift Gauges, LLC | All Rights Reserved DODGE RAM 24V 5.9/6.7L CUMMINS Reconnect the negative terminals of the two batteries to prepare power for the gauges and to test the fuses for power with a Test Light. 1. Run the power wires through the firewall and into the engine bay of the truck. Note: You may need to drill a hole in the firewall if there isn’t one present. It is important to use a Grommet on the hole to ensure the wires are not sliced or cut on the firewall. 2. Drill a hole in the side of the fuse box located under the hood in order to run the wires inside without them being pinched on the fuse box lid. Be careful not to damage anything while drilling. Note: Steps 3, 4, and 5 are based on a 2009 vehicle. Please refer to the chart below for the fuse locations for your specific vehicle. Be sure that two fuses are installed in each Expandable Circuit. 3. Locate and remove fuse #31 POWERTRAIN CONTROL MODULE (10A) from the fuse panel. Using the Expandable Circuit, crimp the yellow wires to the Expandable Circuit and insert the circuit into the empty fuse #31 slot. 4. Locate and remove fuse #33 HEATING AND A/C (10A) from the fuse panel. Using the Expandable Circuit, crimp the red wires to the Expandable Circuit and insert the circuit into the empty fuse #33 slot. 5. Locate and remove fuse #16 RIGHT FRONT PARKING / TURN LAMP (15A) from the fuse panel. Using GlowShift’s Expandable Circuit (Optional), crimp the orange wires to the Expandable Circuit and insert the circuit into the empty fuse #16 slot. 6. Connect the black wire to any bare metal grounding location. If the black wire is not connected to a bare metal grounding location the gauges will not power on. Tip: Remove all rust and paint from the grounding location for a better connection. 7. Secure any excess wiring with Zip Ties. 8. Reinstall the dash side cover and any interior trim that was removed. Check and fill the Transmission Fluid according to manufacturer specifications. 9. Power the truck on to see if the gauges are functioning properly and check for any leaks or loose sensor connections. 10. Press the Color Change Button on the gauges to ensure they are working correctly. Note: MaxTow Gauges do not change colors. The button allows you to change the 3 Daytime and 3 Nighttime Brightness Levels. 11. Test drive your vehicle to ensure all gauges are functioning properly. Note: The Boost Gauge will only read while driving. Connecting to Power SECTION 7 Fuse # Description Fuse Size Fuse Type 2003-2005 Yellow Constant Wire 45 Horn Relay 20 Amp Mini Red Switched Wire 27 Heated Mirror 10 Amp Mini Orange Headlight Switched Wire 32 Park/Turn Signal Lamp 10 Amp Mini 2006-2009 Yellow Constant Wire 31 Powertrain Control Module 10 Amp Mini Red Switched Wire 33 Heating and A/C 10 Amp Mini Orange Headlight Switched Wire 16 Right Front Park/ Turn Lamp 15 Amp Mini 2003-2005 Fuse Box 2006-2009 Fuse Box
